Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual page 76

Instruction Functions
Instruction Symbol/Operand
Mnemonic
Code
ACCUMULATIVE Timer
TTIM(087)
input
TIMER
TTIM
087
(BCD)
Reset
input
TTIMX
N: Timer number
555
S: Set value
(Binary)
(CS1-H, CJ1-H,
CJ1M, or CS1D
Timer
TTIMX(555)
only)
input
Reset
input
N: Timer number
S: Set value
LONG TIMER
TIML(542)
TIML
542
(BCD)
TIMLX
553
(Binary) D1: Completion
(CS1-H, CJ1-H,
Flag
CJ1M, or CS1D D2: PV word
only)
S: SV word
TIMLX(553)
D1: Completion
Flag
D2: PV word
S: SV word
36
TTIM(087)/TTIMX(555) operates an incrementing timer with units of
0.1-s. The setting range for the set value (SV) is 0 to 999.9 s for
N
BCD and 0 to 6,553.5 s for binary (decimal or hexadecimal).
S
Timer input
Timer PV
N
S
Completion
Flag
Reset input
TIML(542)/TIMLX(553) operates a decrementing timer with units of
0.1-s that can time up to approx. 115 days for BCD and 49,710 days
D1 for binary (decimal or hexadecimal).
Timer input
D2
S
Timer PV
Completion Flag
(Bit 00 of D1)
D1
D2
S
Function
SV
SV
Section 2-2
Location
Execution
condition
Output
Required
Timing resumes.
PV maintained.
Output
Required
Page
262
266
