Data Control Instructions
Operand Specifications
796
P1
P1+1
P1+2
P1+3
Note P1 to P1+3 must be in the same area.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
15
Scaled value for point A (Ar)
0000 to 9999 (4-digit BCD)
15
Unscaled value for point A (As)
0000 to FFFF (binary)
15
Scaled value for point B (Br)
0000 to 9999 (4-digit BCD)
15
Unscaled value for point B (Bs)
0000 to FFFF (binary)
S
CIO 0000 to CIO CIO 0000 to CIO
6143 6140
W000 to W511 W000 to W508
H000 to H511 H000 to H508
A000 to A959 A000 to A956
T0000 to T4095 T0000 to T4092
C0000 to C4095 C0000 to C4092
D00000 to D00000 to
D32767 D32764
E00000 to E00000 to
E32767 E32764
En_00000 to En_00000 to
En_32767 En_32764
(n = 0 to C) (n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
---
DR0 to DR15 ---
Section 3-18
0
0
0
0
P1 R
CIO 0000 to CIO
6143
W000 to W511
H000 to H511
A448 to A959
T0000 to T4095
C0000 to C4095
D00000 to
D32767
E00000 to
E32767
En_00000 to
En_32767
(n = 0 to C)
DR0 to DR15
