Table Data Processing Instructions
Description
Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
SUM(184) adds C units of data beginning with the data in R1 and outputs the
result to D+1 and D. The settings in C+1 determine whether the units are
words or bytes, whether the data is binary (signed or unsigned) or BCD, and
whether to start with the right or left byte of R1 if bytes are being added.
When bit 14 of C+1 has been set to 0, SUM(184) treats the data as binary. In
this case, bit 15 determines whether the data is signed (bit 15 = 1) or
unsigned (bit 15 = 0).
When bit 13 of C+1 has been set to 1, SUM(184) adds bytes of data. In this
case, bit 12 determines whether the calculation starts with the rightmost byte
of R1 (bit 12 = 1) or the leftmost byte of R1 (bit 12 = 0).
+)
D+1
Note SUM(184) can be processed in the background. Refer to the SYSMAC CS/
CJ/NSJ Series PLC Programming Manual (W394) for details.
C
E00000 to E00000 to
E32766 E32767
En_00000 to En_00000 to
En_32766 En_32767
(n = 0 to C) (n= 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Specified values ---
only
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
S
Table length
specified in C
The actual table length specified
in C depends upon the units
(words or bytes) set in C+1.
D
Section 3-17
R1 D
E00000 to
E32766
En_00000 to
En_32766
(n = 0 to C)
737
