Storage Columns
Figure 1-3. Storage columns
Storage columns within the library store cartridges while they are not being
utilized by a drive. The library contains six storage columns. One of those six
columns is the I/O Station.
Robotic System
Figure 1-4. Robotic System of the library
The Robotic System includes the Y-axis Assembly which houses the Y Motor (
in Figure 1-4), the Picker (
Figure 1-4), and the Bar Code Scanner (
Robotic System within the library.
The Picker (robotic arm) has fingers that enable it to grab tape cartridges and move
them to and from the I/O Station, storage slots, and drives. The Bar Code Scanner
2
3
2
in Figure 1-4) which is attached to the Carrier (
1
4
4
in Figure 1-4). The Climber moves the
Chapter 1. Product Description
3
1
in
1-7
