Library and Logical Libraries

Viewing System Information

Viewing Library Map

|
|

Accessing the Setup Wizard

Library Verify Diagnostic Tests

8-2
TS3310 Tape Library Setup and Operator Guide
The following sections give information on operating procedures related to the
library or logical libraries within your library.
From the Web User Interface: Monitor System → System Summary
This menu item gives information on the overall health of the library, as well as,
the current assignment of I/O slots, drives, cleaning cartridge slots, and storage
slots.
From the Web User Interface: Monitor System → Library Map
This menu item displays a visual representation of the library, showing cleaning
slots, I/O slots, storage slots, and unused slots in different colors.
From the Operator Panel: Setup → Setup Wizard
For information on using the Setup Wizard, refer to Chapter 7, "Configuring the
Library," on page 7-1.
From the Operator Panel: Tools → Service → SystemService → System
1. Follow the menu path shown above.
2. Touch Yes to take all logical libraries OFFLINE.
3. Select Library, then choose one of the following diagnostic tests and follow the
on-screen instructions:
v Robotics - tests the library robotics (see "DR005: Motion Failure Diagnostic (a
Library Verify Test)" on page 11-35)
