T085: Cleaning Slot Occupied By Non Imported Cartridge - IBM System Storage TS3310 Setup And Operator Manual

Root Causes
Possible CRU Replacements
Resolution

T085: Cleaning slot occupied by non imported cartridge

Description
Detection Scenario
Root Causes
Possible CRU Replacements
Resolution
1. User removes cartridge manually instead of via
export cleaning media GUI functionality.
2. Bar code label on a system cleaning cartridge is not
read during inventory.
3. Any scenario where a properly imported system
cleaning cartridge which has not yet been properly
exported is detected to be missing based on library
inventory operations.
Cleaning cartridge
Perform "DR042: Import a Library Cleaning Cartridge"
on page 11-46.
When using the library to manage drive cleaning, the
cleaning cartridges that are imported into the library are
not visible to any host and are not part of any partition.
Rather, they are in the "system" partition. Under all
circumstances, the user should use the import and export
cleaning cartridge functions to move cleaning cartridge
into and out of the cleaning slots in this "system"
partition. If the library becomes aware during inventory
that an unexpected (non-imported) cartridge has been
inserted into a cleaning slot manually (through an open
door and/or with the power OFF) this ticket will be
used to notify the user that this slot contains cartridge
that cannot be used for cleaning. Because the cartridge
was not imported as a cleaning cartridge, the library
cleaning functionality is no longer in tact. It is either
degraded (less valid cleaning cartridges available) or
totally absent (no valid cleaning cartridge in the library).
1. When library inventory occurs during robot
initialization from a power ON.
2. When library inventory occurs during robot
initialization from a door close.
1. User adds a cartridge manually instead of via the
import cleaning media GUI functionality.
2. Any time a cleaning slot is defined via the GUI
functionality and there is a rogue, labeled cartridge in
the slot. This can occur under door open conditions
or covers off.
3. Any scenario where a bar code labeled cartridge ends
up in a cleaning slot by means other than via the
proper import GUI functionality.
Cleaning cartridge
Perform "DR042: Import a Library Cleaning Cartridge"
on page 11-46.
Chapter 11. Service Action Tickets (Txxx) and Diagnostic Resolutions (DRxxx)
11-33
