Adjusting the PTO Clutch

Chassis: Adjustments
g314284
1. PTO clutch
2. Wire harness connector
1. Use the access slots in the clutch cover to measure the gap between the
clutch rotor and the armature. The gap should be 0.3 to 0.6 mm (0.012 to
0.024 inch) at all the 3 access slots.
2. If the gap is incorrect, loosen or tighten the 3 locknuts to achieve the correct
gap at each access slot.
Figure 110
3. Access slot (3 each)
4. Locknut (3 each)
Page 7–4 Groundsmaster ® 3200, 3300 and 3310
19240SL Rev A
