4
.
1
.
2
.
4
L
A
N
S
t
a
t
u
s
4
.
1
.
2
.
4
L
A
N
S
t
a
t
u
s
This page allows you to check LAN status of the router.
Each item will be explained as follows:
Item
Refresh
Name
IP Address
MAC Address
RX Packet
TX Packet
Alias
4
.
1
.
2
.
5
E
t
h
e
r
n
e
t
4
.
1
.
2
.
5
E
t
h
e
r
n
e
t
This page can define the details settings of the LAN ports in a profile, including IP settings,
physical interface members (LAN ports on the front panel of the router) and wireless
interfaces (SSID and WDS settings).
Currently, two LAN interfaces may be configured for the Vigor2760. Each LAN interface can
be configured to support different firewall settings, servers, and applications according to the
settings in other configuration web pages
Available parameters are listed below:
Item
Add
Edit
Description
Click it to refresh the web page.
Display the profile name for LAN interface.
Display the LAN IP address of the router.
Display the MAC address of the router.
Display the total received packets via such LAN interface.
Display the total transmission packets via such LAN
interface.
Display the IP alias setting.
Description
Create new LAN profiles.
Edit the selected LAN profile.
82
Vigor2760 Series User's Guide
