2. Click Edit to open the following page.
Available parameters are listed below:
Item
Backup
Name
SIM Pin Code
Modem Initial String
1/2
APN Name
Modem Dial String
PPP Username
PPP Password
Confirm PPP
Password
Default Route
Apply
Clear
Vigor2760 Series User's Guide
Description
Check the box to enable such profile.
Type the name of the profile.
Type PIN code of the SIM card that will be used to access
Internet.
Such value is used to initialize USB modem. Please use the
default value. If you have any question, please contact to
your ISP.
The initial string 1 is shared with APN. In some cases, users
may need another initial AT command to restrict 3G band or
do any special settings.
APN (Access Point Name) is provided by your ISP for
identifying different access points.
Such value is used to dial through USB mode. Please use the
default value. If you have any question, please contact to
your ISP.
Type the PPP username (optional).
Type the PPP password (optional).
Type the password again for confirmation.
Check the box to enable the default route for such WAN
profile.
Click it to save the settings.
Click it to remove the modification of the web page.
