4 . 7 . 1 S I P A c c o u n
4 . 7 . 1 S I P A c c o u n
In this section, you set up your own SIP settings. When you apply for an account, your SIP
service provider will give you an Account Name or user name, SIP Registrar, Proxy, and
Domain name. (The last three might be the same in some case). Then you can tell your folks
your SIP Address as in Account Name@ Domain name
As Vigor VoIP Router is turned on, it will first register with Registrar using
AuthorizationUser@Domain/Realm. After that, your call will be bypassed by SIP Proxy to the
destination using AccountName@Domain/Realm as identity.
Note: Selection items for Ring Port will differ according to the router you have.
Each item will be explained as follows:
Item
Edit
Refresh
Reset
Profile Name
Register via
Domain/Realm
Proxy
Account Number/Name
Ring Port
Status
t s
t s
Description
Modify the selected SIP account profile.
You have to check the SIP account profile you want and then
click this button to open the edit window for modification.
Click it to fresh the web page.
Click it to retrieve the default settings of this page.
Display the names of the SIP accounts. Account 1 ~ Account
6 are named in default.
Display the registration interface of such SIP account.
Display the domain name or IP address of the SIP registrar
server.
Display the domain name or IP address of the SIP proxy
server.
Display the account name of SIP address before @.
Specify which port will ring when receiving a phone call.
Show the status for the corresponding SIP account. R means
such account is registered on SIP server successfully. –
means the account is failed to register on SIP server.
