1 . 1 . 2 F o r V i g o
1 . 1 . 2 F o r V i g o
LED
(Activity)
(Wireless LAN
On/Off/WPS)
DSL (Green)
~
LAN1/2/3/4
~
USB1/2
Vigor2760 Series User's Guide
r 2 7 6 0 n
r 2 7 6 0 n
Status
Blinking
Off
On (Green)
Blinking
(Green)
Blinking
(Orange)
Off
On
Blinking
(Slowly)
Blinking
(Quickly)
On
Blinking
(Green)
On
Explanation
The router is powered on and running normally.
The router is powered off.
The wireless access point is ready.
The data is transmitting via wireless connection.
Blinks with one second cycle for two minutes. The WPS
function is active.
The wireless access point is turned off.
The DSL port is connected.
The router is ready.
The router is trying to connect to Internet.
The port is connected.
The data is transmitting.
A USB device is connected and active.
