Draytek Vigor2760 User Manual page 151

Name
Description
Type
Schedule
Quality of Service
Action
To add a filter rule profile, please do the following:
1. Click Add.
2. The following page appears.
Available parameters are listed below:
Item
Enable
Name
Description
Type
Vigor2760 Series User's Guide
Disable – The rule is not activated.
Display the name of the rule profile.
Display filter set comments/description.
Display the direction of packet flow
Display the profile(s) that the filter rule will be valid at
certain time interval
Display the QoS class applied by such profile.
Display the action to be taken when packets match the rule.
Description
Check the box to enable the profile.
Type the name of the rule profile. Maximum length is 15-
character long.
Enter filter set comments/description.
Set the direction of packet flow.
141
