Call Barring Advanced - Draytek Vigor2760 User Manual

4 . 7 . 3 . 4
4 . 7 . 3 . 4
Additionally, you can set advanced settings for call barring such as Block Anonymous, Block
Unknown Domain or Block IP Address. Simply click the relational links to open the web
page.
Available parameters are listed below:
Item
Enable Block Anonymous
Block Anonymous
Interface
Enable Block Unknown
Domain
Enable Unknown Domain
Interface
Enable Block IP Address
Block IP Address
Interface
Apply
Clear
Reset
Vigor2760 Series User's Guide
C a l l B a r r i n g A d v a
C a l l B a r r i n g A d v a
n c e d
n c e d
Description
This function can block the incoming calls without caller ID
on the interface (Phone port) specified in the following
window. Such control also can be done based on
preconfigured schedules.
Specify the interface (phone 1 and / or phone 2) to apply the
function.
This function can block incoming calls (through Phone port)
from unrecognized domain that is not specified in SIP
accounts. Such control also can be done based on
preconfigured schedules.
Specify the interface (phone 1 and / or phone 2) to apply the
function.
This function can block incoming calls (through Phone port)
coming from IP address. Such control also can be done
based on preconfigured schedules.
Specify the interface (phone 1 and / or phone 2) to apply the
function.
Click it to save the settings.
Click it to remove the modification of the web page.
Click it to rest to factory default settings.
217
