Vpn And Remote Access; Service Control - Draytek Vigor2760 User Manual

4 . 1 1 V P N a n d
4 . 1 1 V P N a n d
A Virtual Private Network (VPN) is the extension of a private network that encompasses links
across shared or public networks like the Internet. In short, by VPN technology, you can send
data between two computers across a shared or public network in a manner that emulates the
properties of a point-to-point private link.
Below shows the menu items for VPN and Remote Access.
4 . 1 1 . 1 S e r v i c
4 . 1 1 . 1 S e r v i c
Enable the necessary VPN service as you need. If you intend to run a VPN server inside your
LAN, you should disable the VPN service of Vigor Router to allow VPN tunnel pass through,
as well as the appropriate NAT settings, such as DMZ or open port.
Available parameters are listed below:
Item
PPTP VPN Service
L2TP VPN Service
IPsec VPN Service
IP Range
Apply
Clear
Vigor2760 Series User's Guide
R e m o t e A c c
R e m o t e A c c
e C o n t r o l
e C o n t r o l
e s s
e s s
Description
Check the box to enable such service.
Check the box to enable such service.
Check the box to enable such service.
Determine the IP range for above services.
When LAN DHCP is disabled, the system will assign the IP
address for remote dial-in user within the IP range.
Click it to save the settings.
Click it to remove the modification of the web page.
251
