Draytek Vigor2760 User Manual page 301

Delete
Reset
Refresh
Enable
Get Community
To add a SNMP profile, please do the following:
1. Click Add.
2. The following page appears.
Available parameters are listed below:
Item
SNMP Enable
Get Community
Manager IP
SNMP Event
Vigor2760 Series User's Guide
Remove the selected SNMP profile.
Click it to rest to factory default settings.
Click it to refresh the web page.
Display the activation status for such interface.
Enable – The SNMP profile is activated.
Disable –The SNMP profile is not activated.
Display the name for getting community.
Description
Check the box to enable such profile.
Set the name for getting community by typing a proper
character. The default setting is public.
Set one host as the manager to execute SNMP function.
Please type in IP address to specify certain host.
Click the + button to add a new IP address.
Specify the items to be executed by SNMP function.
291
