Draytek Vigor2760 User Manual page 197

2. The following setting page will appear.
Available parameters are listed below:
Item
Name
Server IP Address
Port
Server Password
Confirm Server
Password
Apply
Clear
Cancel
3. After finished the settings above, click Apply to save the file. Now, a new RADIUS
profile has been created.
Vigor2760 Series User's Guide
Description
Type a name for the RADIUS server.
Type the IP address of RADIUS server
The UDP port number that the RADIUS server is using. The
default value is 1812, based on RFC 2138.
The RADIUS server and client share a password that is used
to authenticate the messages sent between them. Both sides
must be configured to use the same password.
Re-type the password for confirmation.
Click it to save the settings.
Click it to remove the modification of the web page.
Click it to return to previous web page.
187
