Wan Bridge - Draytek Vigor2760 User Manual

4 . 1 . 1 . 1
4 . 1 . 1 . 1
Bridge connections can be configured on the Vigor router, making the router work partially as
a bridge modem. It can be configured from the Bridge tab located in the Network >> WAN
web page.
Each item will be explained as follows:
Item
Add
Edit
Delete
Refresh
Enable
Name
Description
Bridge Profile Type
To add a new WAN profile, please do the following:
1. Click the Add button.
2. The following setting page will appear.
Vigor2760 Series User's Guide
0 W A N B r i d g e
0 W A N B r i d g e
Description
Create new WAN profiles.
Edit the selected WAN profile.
To edit the profile, simply check the profile box you want to
edit and then click this button.
Remove the selected WAN profile.
Click it to refresh the web page.
Display the activation status for such DSL interface.
Enable – The DSL interface is activated.
Disable – The DSL interface is not activated.
Display the profile name for DSL/USB interface.
Display a brief description for such profile.
Display which type of DSL network (ADSL or VDSL2) this
bridge will connect to.
75
