4 . 1 0 . 1 U S B S t a t u
4 . 1 0 . 1 U S B S t a t u
This page displays the "storage" status of the USB disk which users can access via FTP or
Samba. If you plug in one USB disk, related information will be shown here. If you plug in
two USB disks, then both of them will be displayed at the same time.
4 . 1 0 . 1 . 1 D
4 . 1 0 . 1 . 1 D
This page display the general information of the USB disk connected.
Each item will be explained as follows:
Item
Refresh
Usage
Total
Used
Available
File System
Device
Mount Path
4 4 . . 1 1 0 0 . . 1 1 . . 2 2 P P r r
This page display the general information of the USB printer connected.
Each item will be explained as follows:
Item
Refresh
Status
s
s
i s k S t a t u s
i s k S t a t u s
Description
Click it to fresh the web page.
Display the percentage of the disk space used.
Display the total storage of the disk.
Display the disk space in used.
Display the remaining disk space.
Display the file system of the disk.
Display the type of the hardware storage disk.
Display the file system path where a storage device can be
accessed.
i i n n t t e e r r S S t t a a t t u u s s
Description
Click it to fresh the web page.
Display the activation status of the USB disk.
Enable – The USB printer is available for printing.
Disable – The USB printer is not powered up.
242
Vigor2760 Series User's Guide
