Call Forward [DeAct]
Do Not Disturb [Act]
Do Not Distrub [DeAct]
Hide Caller ID [ACT]
Hide Caller ID [DeACT]
Call Waiting [ACT]
Call Waiting [DeACT]
Apply
Clear
Reset
4 . 7 . 4 P h o n e S
4 . 7 . 4 P h o n e S
From this page, you can find codec, connection and other important call status for each port.
Each item is explained as follows:
Item
Refresh
Port
Status
Vigor2760 Series User's Guide
t a t u s
t a t u s
or there is no answer of the connected phone.
Dial the number typed in this field to release the call forward
function.
Dial the number typed in this field to invoke the function of
DND.
Dial the number typed in this field to release the DND
function.
Dial the number typed in this field to make your phone
number (ID) not displayed on the display panel of remote
end.
Dial the number typed in this field to release this function.
Dial the number typed in this field to make all the incoming
calls waiting for your answer.
Dial the number typed in this field to release this function.
Click it to save the settings.
Click it to remove the modification of the web page.
Click it to rest to factory default settings.
Description
The information will update immediately when the Refresh
button is clicked.
It shows current connection status for Phone(s) ports.
It shows the VoIP connection status.
IDLE - Indicates that the VoIP function is idle.
HANG_UP - Indicates that the connection is not
established (busy tone).
CONNECTING - Indicates that the user is calling out.
WAIT_ANS - Indicates that a connection is launched and
waiting for remote user's answer.
ALERTING - Indicates that a call is coming.
ACTIVE-Indicates that the VoIP connection is launched.
219
