4 . 4 . 2 S e r v i c e T y p
4 . 4 . 2 S e r v i c e T y p
Service types with specified ports are usually applied in configuring router's settings. For the
convenience, this feature offers several default set of service type with port value for you to
use. Moreover, it allows you to define other service types by yourself.
4 . 4 . 2 . 1 S e r
4 . 4 . 2 . 1 S e r
This page is simply used to define the service type object.
Each item will be explained as follows:
Item
Add
Edit
Delete
Reset
Refresh
Name
Protocol
Application
To create a new service type object profile, please do the following:
1. Click the Add button.
e
e
v i c e T y p e O b j e c t
v i c e T y p e O b j e c t
Description
Create a new service type profile.
Modify the selected service type profile.
You have to check the service type you want and then click
this button to open the edit window for modification.
Remove the selected service type.
You have to check the service type you want and then click
this button.
Click it to retrieve the default settings of this page.
Click it to fresh the web page.
Display the name of the profile.
Display the protocol that this profile applies to.
Display the type (e.g., HTTP, POP3 and etc.) of such profile.
