Draytek Vigor2760 User Manual page 75

Delete
Refresh
Enable
Name
Description
Profile Type
PVC Binding
VPI
VCI
IP Version
To add a new WAN profile, please do the following:
1. Click the Add button.
2. The following setting page will appear.
Vigor2760 Series User's Guide
To edit the profile, simply check the profile box you want to
edit and then click this button.
Remove the selected WAN profile.
Click it to refresh the web page.
Display the activation status for such DSL interface.
Enable – The DSL interface is activated.
Disable – The DSL interface is not activated.
Display the profile name for DSL/USB interface.
Display a brief description for such profile.
Display the nature (ADSL, VDSL2 or both) for such profile.
Display the PVC profiles selected by such profile.
Display the value of VPI.
Display the value of VCI.
Display the IP version (IPv4 or IPv6) for such connection.
65
