To edit the bandwidth management profile, please do the following:
1. Choose on the SSID you want to edit and click the check box.
2. Click the Edit button to open the following page.
Available parameters are listed below:
Item
Name
Enable
Bandwidth Limit
Type
Total Upload Limit
(Kbps)
Total Download
Limit (Kbps)
Apply
Clear
Cancel
3. After finished the settings, click Apply to save the configuration.
Description
Display the name of the SSID profile. Such name is assigned
by the router in default.
Check this box to activate the function of limit bandwidth.
The bandwidth limit determined by the system automatically
(Auto Adjustment) or by the station (Per Station Limit).
Define the speed of the upstream for each wireless station.
Define the speed of the downstream for each wireless
station.
Click it to save the settings.
Click it to remove the modification of the web page.
Click it to return to previous web page.
