Network
My WAN IP
Local Subnet
Remote LAN
Gateway
Remote LAN
Subnet Mask
More Subnet
Apply
Clear
Cancel
3. After finished the settings above, click Apply to save the file.
Now, a new LAN to LAN profile has been created.
Vigor2760 Series User's Guide
Dead Peer Detection – Delay Time (sec) – It is available
when Clear is selected for Dead Peer Detection above. Set
the interval for the detection. The default setting shall be "30"
seconds.
Dead Peer Detection – Timeout (sec) –It is available when
Clear is selected for Dead Peer Detection above. Set the time
that the system will wait for the response. The default setting
shall be "120" seconds. In default, the detection will be done
for four times within the default time. If there is no response,
the VPN tunnel will be disconnected.
Type the WAN IP address for the VPN tunnel.
Add a static route to direct all traffic destined to Local Subnet
through the VPN connection.
This field is only applicable when you select PPTP or L2TP
with or without IPsec policy above. Type the LAN gateway
address of the remote router for the VPN tunnel.
Add a static route to direct all traffic destined to this Remote
LAN Subnet Mask through the VPN connection. For IPsec,
this is the destination clients IDs of phase 2 quick mode.
Add a static route to direct all traffic destined to more Remote
Network IP Addresses/ Remote Network Mask through the
VPN connection. This is usually used when you find there are
several subnets behind the remote VPN router.
Click it to save the settings.
Click it to remove the modification of the web page.
Click it to exit the web page without saving the configuration.
