Usb Applications - Draytek Vigor2760 User Manual

object
MAC Address
Schedule
Apply
Clear
Cancel
3. After finished the settings above, click Apply to save the file. Now, a new WOL profile
has been created.
4 . 1 0 U S B A p p
4 . 1 0 U S B A p p
USB storage disk connected on Vigor router can be regarded as a server. By way of Vigor
router, clients on LAN can access, write and read data stored in USB storage disk with
different applications. Then, the client can use the FTP site (USB storage disk) or share the
Samba service through Vigor router.
Vigor2760 Series User's Guide
l i c a t i o n s
l i c a t i o n s
box for specifying the address object.
Address Object – Use the drop down list to choose one of
the existed address object profiles.
Manually type the MAC address of the device that you want
to wake up. Or click Select to choose the one you want.
Use the ">" button to move the selected item listed in
Available Items onto Selected Items.
Available Items – Display the available schedule profiles.
Selected Items – Display the schedule profiles selected for
such group.
Click it to save the settings.
Click it to remove the modification of the web page.
Click it to return to previous web page.
241
