3. After finished the settings above, click Apply to save the settings.
4 . 1 . 5 R o u t e P o l i c
4 . 1 . 5 R o u t e P o l i c
Route Policy (Cisco called it "policy-based routing") is a feature where a set of rules or
"policies" are defined first. Then, if there comes a packet that matches any one of the
"policies", it will be directed to the specified interface.
Each item will be explained as follows:
Item
Add
Edit
Delete
Reset
Refresh
Enable
Name
Protocol
Interface
Src IP Start/
Src IP End
Dest IP Start/
Dest IP End
Click it to remove the modification of the web page.
Click it to return to previous web page.
y
y
Description
Create new policy route profiles.
Edit the selected policy route profile.
To edit the profile, simply check the profile box you want to
edit and then click this button.
Remove the selected policy route profile.
Click it to rest to factory default settings.
Click it to refresh the web page.
Display the activation status for such interface.
Enable – The profile is activated.
Disable –The profile is not activated.
Display the profile name for the static route.
Display the protocol used for this policy.
Display the interface used for this policy.
Displays the IP address for the start/end of the source IP.
Displays the IP address for the start/end of the destination IP.
100
Vigor2760 Series User's Guide
