tag. The router will add specific VLAN number to all packets
while sending them out. Please type the tag value and specify
the priority for the packets sending by the router.

VLAN ID –Type the value as the VLAN ID
number. The range is form 1 to 4000.

Priority (802.1p) - Type the packet priority
number for such VLAN. The range is from 0 to 7.
IPv4 Setting – It is available when IPv4 is selected as IP
Version.

PPP Fixed IP - Type a fixed IP address for PPP
connection.

Default Route - Check the box to enable the
default route for such WAN profile.
IPv6 Setting – It is available when IPv6 is selected as IP
Version.

Prefix Length – Type the fixed value for prefix
length.

Prefix Send To – Choose the interface (LAN).

Default Route - Check the box to enable the
default route for such WAN profile.
Detect Setting - Such function allows you to verify whether
network connection is alive or not through or Ping detection
or Auto detection.

Connection Detection - Check the box of
Connection Detection to enable such function.

Connection Detection Mode - Choose the
detection mode.
Always On - If you want to connect to Internet all the time,
check the Always On box.
When PPPoA is selected under Both / ADSL
Username - Type in the username provided by ISP in this
field.
Password - Type in the password provided by ISP in this
field.
Confirm Password - Type in the password again for
confirmation.
PPP Authentication - Select PAP only or PAP or CHAP
for PPP.
MTU - It means Max Transmit Unit for packet. The default
setting will be 1492.
IPv4 Setting – It is available when IPv4 is selected as IP
Version.

PPP Fixed IP - Type a fixed IP address for PPP
connection.

Default Route - Check the box to enable the
default route for such WAN profile.
IPv6 Setting – It is available when IPv6 is selected as IP
Version.
