The application for the WDS-Repeater mode is depicted as below:
In Bridge mode, the router will connect to up to four Vigor2760 which use the same mode,
and all wired Ethernet clients of every Vigor2760 will be connected together. You can use this
mode to connect a network to other networks which is physically isolated. Please note that
when you set to this mode, Vigor2760 will not accept regular wireless clients anymore.
In Repeater mode, the router will connect to up to four Vigor2760 which use the same mode,
and all wired Ethernet clients of every Vigor2760 will be connected together. You can use this
mode to connect a network to other networks which is physically isolated. When you use this
mode, this access point is still able to accept wireless clients.
Open Wireless LAN>>WDS to open the following page. It allows you to enable the WDS
setting, specify WDS mode (Bridge or Repeater) and modify the WDS settings.
Available parameters are listed below:
Item
Enable
Mode
Description
Check this box to enable WDS setting.
Choose the mode for WDS setting. Bridge mode is designed
to fulfill the first type of application. Repeater mode is for the
second one.
