To view Ethernet port statistics:
1 From the Card Statistics menu, shown earlier in Figure 161, enter the number
corresponding to the Ethernet port for which you want to view statistics to open
the Ethernet Statistics menu shown in Figure 163.
Figure 163 Ethernet Statistics Menu
2 Select the option corresponding to the type of statistic you want to view:

Ethernet statistics

Ethernet Spanning Tree Statistics
IP over ATM Statistics
ATM VC Statistics
The following subsections describe these categories of statistics.
Ethernet Statistics
The Ethernet Statistics screen (for either the standard 10BASE-T Ethernet port or
the optional 10/100BASE-T Ethernet port) displays the following statistics:
Bridge Statistics
Port state — The state of the Ethernet port: connected or not connected
Total frames received — The total number of frames received at this port
Broadcast Frames — The number of broadcast frames received on the port
Spanning Tree Frames — The number of Spanning Tree frames received on the
port
Discarded Frames — The number of valid frames received that were discarded
(filtered) by the forwarding process
Flooded Frames — The total number of incoming frames that were flooded on
this port
Forwarded Frames — The number of incoming frames at this port that were
forwarded
Total frames transmitted — The total number of frames transmitted at this port
