232 A A: S
PPENDIX YSTEM
Voice Compression
Module Connector
Pinouts

Options and Parts List

S P N
PECIFICATIONS AND ART UMBERS
Table 31 lists the connector pinouts for the VCM's T1-DSX port.
Table 31 VCM T1-DSX Pinouts
PIN 1 Rx (ring)
PIN 2 Rx (tip)
PIN 3 NC
PIN 4 Tx (ring)
PIN 5 Tx (tip)
PIN 6 NC
PIN 7 NC
PIN 8 NC
The tables below list available options for the PathBuilder S330/S310 switch.
Contact 3Com or your VAR with the appropriate part number for ordering and
pricing information.
Table 32 PathBuilder S330 Part Numbers
Part Number
3C63300A-AC-NC
3C63300A-DC-NC
3C63303A-AC-NC
3C63303A-DC-NC
3C63304-NC
3C63305-NC
3C63306-NC
3C63307-NC
3C63301
3C63308
3C63311
3C63314
3C63313
3C63318
(continued)
Description
SuperStack II PathBuilder S330 ATM WAN Access Switch Base
System with AC Ethernet, V.35/RS-449 data, OC3/STM-1 UNI mmf,
and n x T1 WAN.
SuperStack II PathBuilder S330 ATM WAN Access Switch Base
System with DC Ethernet, V.35/RS-449 data, OC3/STM-1 UNI mmf,
and n x T1 WAN
SuperStack II PathBuilder S330 ATM WAN Access Switch Base
System with AC Ethernet, V.35/RS-449 data, OC3/STM-1 UNI smf,
and n x T1 WAN
SuperStack II PathBuilder S330 ATM WAN Access Switch Base
System with DC Ethernet, V.35/RS-449 data, OC3/STM-1 UNI smf,
and n x T1 WAN
SuperStack II PathBuilder S330E ATM WAN Access Switch Base
System with AC Ethernet, V.35/RS-449 data, OC3/STM-1 UNI mmf,
and n x E1 WAN
SuperStack II PathBuilder S330E ATM WAN Access Switch Base
System with DC Ethernet, V.35/RS-449 data, OC3/STM-1 UNI mmf,
and n x E1 WAN
SuperStack II PathBuilder S330E ATM WAN Access Switch Base
System with AC Ethernet, V.35/RS-449 data, OC3/STM-1 UNI smf,
and n x E1 WAN
SuperStack II PathBuilder S330E ATM WAN Access Switch Base
System with DC Ethernet, V.35/RS-449 data, OC3/STM-1 UNI smf,
and n x E1 WAN
Optional Four-Port CBR Module with three T1-DSX ports and one
V.35/RS-449 port
Optional Four-Port CBR Module with three E1 ports and one
V.35/RS-449 port
Optional DS1 Voice Compression Module + 1 SIMM
Optional E1 Voice Compression Module + 1 SIMM
Voice Compression SIMM
Optional Ethernet 10/100 Module
