Step 5: Connect the
Management Terminal
In order to configure application connections and an IP address for SNMP support,
you must connect a management terminal to the PathBuilder S330/S310 switch ,
as follows:
1 Connect a VT 100 terminal to the RS-232 (console) port on the front of the
PathBuilder S330/S310.
2 Use the VT100 terminal to input an IP address for the PathBuilder S330/S310
switch. See "Setting up Communication Parameters" in Chapter 3 for details.
3 Establish communication between the PathBuilder S330/S310 and any
management terminal in one of these ways:
Direct RS-232 using the VT100 terminal or VT100 emulator, as described above
Direct 10BaseT on the Management CPU card using an IP Telnet session
Figure 35 illustrates the network management station terminal connection
options.
Figure 35 Network Management Station Terminal Connection Options
10BASE-T
RS-232
VT-100
Installation Procedures
LAN
NMS Terminal
