Viewing CBR Module
Card Statistics
ATM Side Statistics
Received IP Packets—The total number of IP packets received on the virtual
circuit assigned at the port.
Forward IP Packets—The total number of IP packets received from the virtual
circuit and forwarded.
Discarded IP Packets—The total number of IP packets received from the virtual
circuit and dropped.
RX ARP Request—The total number of ARP request packets received on the
virtual circuit.
RX ARP Reply—The total number of ARP response packets received on the virtual
circuit.

Ethernet ATM VC STatistics

The Ethernet ATM Statistics screen displays the following ATM VC statistics for the
Ethernet port:
VC# — The system-assigned virtual circuit number
(Side A) card s/p — The slot and port number for side A of the circuit
(Side A) rx — The receive VCI/VPI for side A
(Side A) tx — The transmit VCI/VPI for side A
(Side B) card s/p — The slot and port number for side B of the circuit
(Side B) rx — The receive VCI/VPI for side B
(Side B) tx — The transmit VCI/VPI for side A
Desc — The user-entered description of the circuit
You can view both performance monitoring and ATM statistics for the CBR
module.
To view CBR statistics:
1 From the Card Statistics menu, shown earlier in Figure 161, select [7] CBR.
2 Select the port for which you want to view statistics.
3 Enter the option corresponding to the type of statistics you want to view:
[1] Performance Monitoring or [2] ATM Statistics.
Viewing Performance and ATM Statistics 201
