Viewing Virtual Circuit
Statistics
Viewing Virtual Circuit
Statistics by Circuit
Voice Compression Module Port Activity Statistics
The VCM Port Activity Statistics screen displays the following statistics for each
channel.
Ch — DS0 channel number
Tx packets — The number of transmitted packets
Rx packets — The number of received packets
Tx bytes — The number of transmitted bytes
Rx bytes — The number of received bytes
The PathBuilder S330/S310 switch provides you with circuit parameters and cell
counts broken down in various ways:
by circuit
by port/group
by shaper
by buffer (queue)
These statistics enable you to look at the cell loss at various points in the data flow
and adjust parameters—such as shaper values—accordingly.
To display virtual circuit statistics by circuit:
1 From the Configuration Management menu, select [2] Manage Circuits to open
the Virtual Circuit menu.
2 From the Virtual Circuit menu, select [5] Show Virtual Circuit Statistics to display a
summary of statistics for all circuits, as shown in Figure 165.
You can also display a summary of virtual circuits by selecting [4] Performance
Management from the main menu to open the Performance Management menu
and then selecting [2] Show Virtual Circuit Statistics.
Viewing Virtual Circuit Statistics
205
