100 C 4: C
HAPTER ONFIGURING
Configuring the
Ethernet Interface
Configuring the
Ethernet Interface
P B S330/S310 M
ATH UILDER ODULES
Figure 89 Configuring the Serial Card
4 Select [1] Set Admin. Status to put the serial card in service or out of service.
The maximum frame size is fixed at 8 KB.
Configuring the standard 10BASE-10 Ethernet interface involves the following
tasks:
Configuring the Ethernet interface
Configuring the bridge (including the spanning tree)
Configuring IP over ATM
The only type of configuration you can perform on the Ethernet interface is to put
the port and card In Service or Out of Service.
To set the administrative status of the Ethernet interface:
1 From the Configuration Management menu, select [1] Manage Card to open the
List Card menu, shown earlier in Figure 60.
2 From the List Card menu, select [6] ETHERNET to open the Ethernet Configuration
menu, shown in Figure 90.
, P , A
ORTS AND PPLICATIONS
