FE Rx Failure — Far-end Rx failure status in the interworking link state machine.
Table 7 lists the possible IMA link failure status conditions.
Table 7 Possible IMA LInk Failure Status Conditions
Failure
link failure
LIF failure
LODS failure
Misconnected
blocked
fault
far end Tx link unusable
far end Rx link unusable
no failure
Tx LID — Transmit logical link ID: 0-31. This number reflects the local IMA ID.
Rx LID — Receive logical link ID: 0-31. This number reflects the remote IMA ID.
Operation Link Delay — The differential link delay referenced to the fastest link
in the same group.
Rx Test Pattern — The received test pattern received: 0-254; 255 indicates that
no pattern has been received.
Test Procedure — The status of the test procedure: disabled, operating, or link
failed.
To view IMA status for a selected group:
1 From the Configuration Management menu, select [1] Manage Card.
2 From the List Card menu, select the number corresponding to the slot in which the
T1 UNI or E1 UNI card is installed to open the Group Menu.
3 Select [4] IMA Group Status to open the Group Status Selection menu, shown in
Figure 80.
, P , A
ORTS AND PPLICATIONS
Description
This is caused by LOS, AIS, OOF, or LCD.
This is caused by LIF.
This is caused by LODS.
This is caused by bad IMA ID, bad link ID, or bad SCCI.
This is caused by AFA, excessive delay, or mismatched protocol.
This is caused by bad M value, bad symmetry, bad offset, or
duplicate link ID.
This is caused by the far end reporting Tx unusable in the ICP
cells.
This is caused by the far end reporting Rx unusable in the ICP
cells.
The link has no failure.
