Rx ICP Cell Error—Number of Rx errored ICP cells since the counter was cleared.
Tx Cell Rate—Current Tx cells per second.
Rx Cell Rate—Current Rx cells per second.
Rx ICP Cell Error Rate—Current Rx errored ICP cells per second.
Avg. Tx Cell Rate—Average Tx data cells rate calculated over the last 8 seconds.
Avg. Rx Cell Rate—Average Rx data cells rate calculated over the last 8 seconds.
Avg. Rx ICP Cell Err Rate—Average Rx errored ICP cells rate calculated over the
last 8 seconds.
DS1 UNI and E1 UNI Group Performance Statistics The T1/E1 Group
Performance screen lists the following statistics:
Running Sec—Count of operational seconds at the near end interworking group
state machine.
Unavailable Sec—Count of unavailable seconds at the near end interworking
group state machine.
NE Number of Failures—Number of failure alarms at the near end.
FE Number of Failures—Number of failure alarms at the far end.
DS1 UNI and E1 UNI Group ATM Statistics The T1/E1 Group ATM Statistics
screen lists the following statistics:
Tx Cells—The number of Tx data cells since the counter was cleared.
Rx Cells—The number of Rx data cells since the counter was cleared.
Rx ICP Cell Error—Number of Rx errored ICP cells since the counter was cleared.
Tx Cell Rate—Current Tx cells per second.
Rx Cell Rate—Current Rx cells per second.
Rx ICP Cell Error Rate—Current Rx errored ICP cells per second.
Avg. Tx Cell Rate—Average Tx data cells rate calculated over the last 8 seconds.
Avg. Rx Cell Rate—Average Rx data cells rate calculated over the last 8 seconds.
Avg. Rx ICP Cell Err Rate—Average Rx errored ICP cells rate calculated over the
last 8 seconds.

Viewing Ethernet Statistics

You can view the following types of statistics for the Ethernet Modules:
Bridging and Ethernet Statistics (per port)
n
Spanning Tree Statistics
n
ATM VC Statistics
n
Bridging and Ethernet Statistics The Bridging and Ethernet Statistics screen
displays the following statistics:
Bridge Statistics
Port state
n
Total frames received
n
Viewing Statistics 209
