Viewing Performance
and ATM Statistics

Setting Tone Injection

To set tone injection:
1 From the VCM Loopback menu, shown earlier in Figure 158, select [3] Set Tone
Injection. You are prompted to enter a channel number.
2 Enter the number of the channel for which you want to set tone injection to open
the VCM Tone Injection menu.
You must have a virtual circuit configured on the voice compression module in
order to use the tone injection feature.
3 Select [1] Set Tone Injection and enter the appropriate number to set tone
injection ON, or OFF. When you set Tone Injection to ON, the system sends a
1000 Hz tone to the PCM interface (T1 or E1). To turn the tone off, set Tone
Injection to OFF.
This section tells you how to display the following types of PathBuilder S330/S310
statistics:
Card Statistics
Performance Monitoring screens list statistics that reflect the physical
monitoring of the line. These screens display one of the following types of
data.
Current — The statistics being collected for the current 15-minute interval.
Interval — The statistics collected over the previous 24 hours of operations,
broken into 96 completed 15-minute intervals.
Total — The cumulative sum of the various statistics for the 24-hour period
preceding the current 15-minute interval.
ATM screens list statistics that monitor the ATM payload. These screens also
display the date and time of the last reset and allow you to clear the
currently-displayed statistics.
Port Activity screen (Voice Compression module) lists statistics that monitor
VCM port activity.
Virtual Circuit Statistics

Viewing Performance and ATM Statistics

185
