T1/E1 UNI with IMA
Interface Connector
Pinouts
Serial Port Connector
Pinouts
Table 20 lists the connector pinouts for the T1/E1 UNI with IMA interface.
Table 20
T1/E1 UNI with IMA Pinouts
PIN 1
Rx (ring)
PIN 2
Rx (tip)
PIN 3
NC
PIN 4
Tx (ring)
PIN 5
Tx (tip)
PIN 6
NC
PIN 7
NC
PIN 8
NC
The connector pinouts for the optional four-port IMA expansion module are the
same as those for the standard T1/E1 UNI with IMA interface.
The following tables list the connector pinouts for the serial port interfaces (V.35,
RS-422, EIA530, and X.21).
PathBuilder S330/S310 cables are compatible with Cisco cables, except for the
DCE EIA530, which Cisco does not manufacture.
Table 21 Connector Pinouts for V.35 DTE Cable (Part #3C63913)
Pin # on 60- pin
Signal Name
Connector
Frame GND
46
Circuit GND
45
RTS
42
CTS
35
DSR
34
DCD
33
DTR
43
LL (not used)
44
SD+
18
SD-
17
RD+
28
RD-
27
SCTE+
20
SCTE-
19
SCR+
26
SCR-
25
SCT+
24
SCT-
23
Shorting GR 1
48, 49
Shorting GR 2
50, 51, 52
Shorting GR 3
53, 54, 55, 56
Connector Pinouts
Pin # onV.35
Direction (for
Connector
Serial Port)
A
B
C
Out
D
In
E
In
F
In
H
Out
K
Out
P
Out
S
Out
R
In
T
In
U
Out
W
Out
V
In
X
In
Y
In
AA
In
