222
A
A: S
PPENDIX
YSTEM
Connector Pinouts
Management Interface
Connector Pinouts
Ethernet Interface
(10BASE-T and
10/100BASE-T)
Connector Pinouts
S
P
N
PECIFICATIONS AND
ART
UMBERS
This section lists the connector pinouts for the interfaces supported by the
PathBuilder S330/S310 WAN access switches.
Table 17 lists the connector pinouts for the management interface.
Table 17
Management Interface Pinouts
PIN 1
Carrier Detect
PIN 2
Rx Data
PIN 3
Tx Data
PIN 4
DTR
PIN 5
Signal Ground
PIN 6
DSR
PIN 7
RTS
PIN 8
CTS
Table 18 lists the connector pinouts for the standard Ethernet 10BASE-T port.
Table 18
Ethernet 10BASE-T Pinouts
PIN 1
Tx+
PIN 2
Tx-
PIN 3
Rx+
PIN 4
NC
PIN 5
NC
PIN 6
Rx-
PIN 7
NC
PIN 8
NC
Table 19 lists the connector pinouts for the optional Ethernet 10/100BASE-TX
module.
Table 19
Ethernet 10/100 BASE-T Pinouts
PIN 1
Tx+
PIN 2
Tx-
PIN 3
Rx+
PIN 4
NC
PIN 5
NC
PIN 6
Rx-
PIN 7
NC
PIN 8
NC
