3Com SuperStack II PathBuilder S330 Reference Manual page 64

50 C 3: G S
HAPTER ETTING TARTED
Figure 45 Local Host IP Configuration Menu
2 Select either [1] Ethernet Port IP Configuration or [2] PCI Ethernet Port IP
Configuration (available only if you have installed the optional Ethernet 10/100
module), depending on whether you want to configure the Ethernet 10BASE-T or
10/100BASE-T (PCI Ethernet) interface.
If you are configuring the 10BASE-T Ethernet interface, select [1] Ethernet Port
IP Configuration to open the Ethernet Port IP Configuration menu, shown in
Figure 46.
If you have installed the optional Ethernet 10/100 module, and you are
configuring the PCI Ethernet interface, select [2] PCI Ethernet Port IP
Configuration to open the PCI Ethernet Port IP Configuration menu. This menu
is similar to the Ethernet Port IP Configuration menu, shown in Figure 46,
except that it does not include an option for setting the community name.
Figure 46 Ethernet Port IP Configuration Menu
