68 C 4: C
HAPTER ONFIGURING
Using the
Configuration
Management Menu
P B S330/S310 M
ATH UILDER ODULES
Serial # — The serial number for the card. This is the same for all ports on the
motherboard. The optional CBR module has a separate serial number.
Rev # — The revision number for the card. This is the same for all ports on the
motherboard, as they come already installed in the unit. The optional CBR module
has a separate revision number.

Verifying Hardware Requirements

In order to execute the release 2.04 software with the new Ethernet 10/100 and
four-port IMA expansion modules, the PathBuilder S330/S310 switch must be
equipped with one of the motherboards listed in Table 4. To check the part and
revision number of the motherboard, view an equipment list as described earlier
under "Viewing an Equipment List" and note the PART#-idprom and Rev # for the
MCPU.
Table 4 Hardware Requirements for Release 2.04
Product
PathBuilder S330/S310
(T1 multi-mode fiber)
PathBuilder S330/S310
(T1 single-mode fiber)
PathBuilder S330/S310
(E1 multi-mode fiber)
PathBuilder S330/S310
(E1 single-mode fiber)
Select [2] Configuration Management from the main menu to open the
Configuration Management menu, shown in Figure 59. Use this menu to access
submenus and screens that allow you to:
Manage cards — View shelf configuration information and configure the
PathBuilder S330/S310 CPU, CTX, ports, CBR module, and Voice Compression
module.
Manage circuits — List, add, modify, and delete virtual circuits.
Manage the bridge — Set the bridge aging timer and configure the bridge.
Manage IP over ATM — Configure and enable/disable IP over ATM for
Ethernet ports (10BASE-T or 10/100BASE-T).
Manage the video dial feature — View the call routing table, manually start
and end video dial-up sessions.
, P , A
ORTS AND PPLICATIONS
MCPU
PART#-idprom
030-11970-0001
030-12009-0001
030-12010-0001
030-12011-0001
MCPU
Rev # Date Revised
CB 12/1/98
CB 12/1/98
CC 12/1/98
CC 12/1/98
