c. Push down on the fan assembly to secure it into the chassis (see letter "C" in
9. Connect the fan cables to the midplane.
10. Install the bridge board. For instructions, see step 6 in
Board" on page
11. Install the large air baffle. For instructions, see
page
12. Install the fan baffle. For instructions, see
13. Install the processor air duct. For instructions, see
Duct" on page
®
Intel
Server System SR2600UR/SR2625UR Service Guide
Figure
123).
B
Figure 123. Installing the Redundant Fan Module
104.
70. Re-route cables through the air baffle as necessary.
57.
C
A
"Installing the Midplane
"Installing the Large Air Baffle" on
"Installing the Fan Baffle" on page
"Installing the Processor Air
AF003024
69.
129
