Front of Intel

Peripheral Devices

The Intel
inch hard drives, a tape drive, CD-ROM drive, or DVD-ROM drive. The drives must be
purchased separately. The following figure shows the available options..
Hard Disk Drive Carriers
The server system ships with eight drive carriers for installing eight SAS or Serial ATA
(SATA) hot-swap 2.5 inch drives.
Note: SAS drives are only supported on the Intel
For instructions on installing hard drives, see
Disk Drive" on page
Note: Drives can consume up to 17 watts of power each. Drives must be specified to run at a
maximum ambient temperature of 45
Note: The Intel
drives. For a web link to a list of supported hard drives, see
Software" on page
®
Intel Server System SR2600UR/SR2625UR Service Guide
®

Server System SR2625UR

®
Server System SR2625UR provides locations and hardware for installing 2.5
C
A. Flex Bay - Tape Drive or two fixed 2.5 inch Hard Disk Drives
(Optional)
B. Slimline SATA Optical Drive Bay
C. 2.5 inch Hard Disk Drive Bays

Figure 14. Optional Peripherals

74.
®
Server System SR2625UR does not support all SAS or Serial ATA (SATA) hard
4.
®
Server System SR2625URLX (active version).
"Installing a Hot-swap SAS/SATA Hard
C.
°
A
B
AF002985
"Additional Information and
27
