Removing and Installing the PCI Riser Assembly

Removing the PCI Riser Assembly

To remove the PCI riser assembly, follow these steps:
1. Disconnect any cables attached to any add-in cards.
2. Grasp the riser assembly with both hands (see letter "A" in
to release it.
3. Lift riser assembly straight up (see letter "B" in
4. Do one of the following:
— If you need to add or replace a PCI add-in card, see
— If you need to add or replace a PCI riser card, see
— If you removed the PCI riser assembly for another procedure, continue with that
50

Figure 32. Removing PCI Riser Assembly from the Server System

PCI Add-in Card" on page
on page 52.
procedure.
Figure
A
B
54.
®
Intel Server System SR2600UR/SR2625UR Service Guide
Figure 33), and pull up
33).
A
Riser Card
Connector
AF002967
"Installing and Removing a
"Replacing a PCI Riser Card"
