A
A. 50-pin Control Panel Connector
B. 10-pin USB Connector for Control Panel
C. Power Connector (for tape drive or 2.5-inch
fixed drives)

RAID Support

The server system provides an embedded SATA controller on the server board that is
accessible through the passive midplane. The SATA controller supports both 1.5 and 3.0
Gbps data transfer rates.
The BIOS Setup utility provides multiple drive configuration options on the Advanced |
ATA Controller setup page, some of which affect the ability to configure RAID. The
Onboard SATA Controller option is enabled by default. When this option is enabled, the
SATA Mode option can be set to either Legacy or Enhanced. The Legacy and Enhanced
modes affect the RAID configuration as follows:
•
Legacy supports four disk drives and does not provide RAID support.
•
Enhanced supports six disk drives and is required for RAID configurations.
When the enhanced mode is selected, you can choose to enable or disable "AHCI Mode"
or "Configure SATA as RAID". The Intel
enabled by the "Configure SATA as RAID" option. The Intel
Technology II feature provides RAID modes 0, 1, and 10.
®
Intel Server System SR2600UR/SR2625UR Service Guide
B C

Figure 22. Hot-Swap SAS/SATA Backplane Components (Rear View)

E
D. Power Connector
E. Midplane Connectors
®
Embedded Server RAID Technology II is
®
Embedded Server RAID
D
AF002789
