Bezels; Rear Of Server System; Figure 15. Server System Back Panel - Intel SR2600UR - Server System - 0 MB RAM Service Manual

Bezels

For information, see

Rear of Server System

A. Low-profile PCI Express* Add-in Card
Slots
B. Full-height PCI Add-in Card Slots
C. Upper Power Supply Module
D. Upper Power Receptacle
E. Lower Power Receptacle
F. Lower Power Supply Module
G. Intel
H. Intel
(Optional)
®
Intel Server System SR2600UR/SR2625UR Service Guide
"Bezels" on page
A
O N L J I H
M K
®
I/O Expansion Module (Optional)
®
Remote Management Module NIC

Figure 15. Server System Back Panel

26.
B
G G
I. NIC 1
J. NIC 2
K. USB 6
L. USB 5
M. DB-9 Serial B Connector
N. Video
O. RJ-45 Serial A Connector
C D
F
E
AF002717
29
