6. Install the large air baffle. For instructions, see
page
7. Install the processor air duct. For instructions, see
Duct" on page
8. Install the PCI riser assembly. For instructions, see
Assembly" on page

Installing and Removing the Server Board

Removing the Server Board

To remove the server board, follow these steps:
1. If installed, remove the PCI riser assembly. For instructions, see
PCI Riser Assembly" on page
2. If installed, remove the processor air duct. For instructions, see
Processor Air Duct" on page
3. Remove the bridge board. For instructions, see step 5 in
Board" on page
4. Remove the large air baffle. For instructions, see
on page
5. Remove the fan module assembly. For instructions, see
on page
6. Remove the I/O expansion module, if installed. For instructions, see
the I/O Expansion Module" on page
116

Figure 108. Removing the RAID Battery Backup Unit

70.
57.
51.
102.
70.
127.
A B
Chassis
Tab(2)
Midplane RAID
BBU Connector
AF002979
"Installing the Large Air Baffle" on
"Installing the Processor Air
"Installing the PCI Riser
50.
56.
"Removing the Large Air Baffle"
97.
®
Intel Server System SR2600UR/SR2625UR Service Guide
"Removing the
"Removing the
"Removing the Midplane
"Replacing a Fan Module"
