Installing The Backplane; Server System Sr2625Ur; Figure 102. Removing The Backplane From The Intel ® Server System Sr2625Ur - Intel SR2600UR - Server System - 0 MB RAM Service Manual

Figure 102. Removing the Backplane from the Intel

Installing the Backplane

To install the backplane, follow these steps:
1. Remove the midplane board. For instructions, see
on page
2. Remove all hot-swap drive carriers, regardless of whether or not a drive is installed
in the carrier. For instructions, see
Drive" on page
3. Depending on your server system, do one of the following:
For Intel
a. Hold the backplane only by the edges. Do not push or pull on any components on
b. Slide the backplane into the server system guides at the left and right sides of the
®
Intel Server System SR2600UR/SR2625UR Service Guide
102.
74.
®
Server System SR2600UR, do the following:
the backplane. Set the backplane in place at the front of the server system, with
the sides of the board resting in the guides at the left and right sides of the server
system.
server system until the pins at the left and right sides of the backplane bracket are
A
B
C
"Removing a SAS or SATA Hot-swap Hard Disk
AF003110
®

Server System SR2625UR

"Removing the Midplane Board"
109
