Intel
Server System SR2600UR Components
A
A.
Rack Handles
B.
SAS/SATA Backplane
C.
Air Baffles
D.
Power Distribution Module
E.
Power Supply Modules (supports up to two
power supply modules)
F.
Riser Card Assembly
G.
Integrated Chassis Intrusion Switch
H.
Processor Air Duct
12
D
C
B
O
N
M
L
A
Figure 3. Intel
Server System SR2600UR Components
®
E
I
J
K
I.
System Memory
J.
System Fan Assembly (redundant option
shown)
K.
Bridge Board
L.
Control Panel (Standard control panel
shown)
M. Flex Bay - Sixth Hard Drive or Tape Drive
or two 2.5 inch Hard Drives (optional)
N.
Hard Drive Bays
O.
Slimline Optical Drive Bay
®
Intel
Server System SR2600UR/SR2625UR Service Guide
F
G
H
AF002816
