Figure 41. Lifting The Processor Socket Handle; Figure 42. Opening The Load Plate - Intel SR2600UR - Server System - 0 MB RAM Service Manual

1. Remove the PCI riser assembly. For instructions, see
Assembly" on page
2. Remove the processor air duct. For instructions, see
Duct" on page 56
3. Remove the heatsink, if installed. For instructions, see
page
4. Locate the processor socket.
5. Push the lever handle down and away from the socket to release it (see letter "A" in
Figure
6. Rotate the lever open all the way (see letter "B" in
7. Push the rear tab with your finger tip to bring the front end of the load plate open
slightly (see letter "A" in
8. Open the load plate (see letter "B" in
9. Remove the protective socket cover (see
Note: Do not touch the orientation posts on the socket; they are very sensitive and easily
damaged.
Note: Retain the protective socket cover for use when removing a processor that will not be
replaced.
60
50.
64.
41).

Figure 41. Lifting the Processor Socket Handle

Figure

Figure 42. Opening the Load Plate

Figure
A
B
AF002835
42).
Figure 42).
B
A
Figure 43).
®
Intel Server System SR2600UR/SR2625UR Service Guide
"Removing the PCI Riser
"Removing the Processor Air
"Removing the Heatsink" on
41).
AF002836
