Hardware Setup
When installing DIMMs, you must follow the following population rules to deliver the best
performance:
Maximize number of channels populated first
Balanced DIMM population across channels and sockets.
DIMM_A2
1 DIMM
-
2 DIMMs
-
3 DIMMs
-
4 DIMMs
6 DIMMs
DIMM_D2
1 DIMM
-
2 DIMMs
-
3 DIMMs
-
4 DIMMs
6 DIMMs
With two processors installed, the system will operate only if the DIMM slots of one
processor are populated. In this case, memory is shared between the two processors.
However, due to the associated latency of this configuration, this is NOT a recommended
operating mode.
You can find additional technical information for the memory sub-system in the Technical
Product Specification (TPS).
2.3.3

Installing a DIMM

CAUTION
Before adding or removing DIMMs or other system components, you
must unplug the power supply. Failure to do so may cause severe
damage to both the server board and the components.
1. Unlock a DIMM socket by pressing the retaining clips outward.
2. Align a DIMM on the socket so the notch on the DIMM matches the break on the
socket.
18

Table 10. Memory Population Table

CPU 1 Configuration
DIMM_A1 DIMM_B2
-
-
-
-
CPU 2 Configuration
DIMM_D1 DIMM_E2
-
-
-
-
DIMM_B1 DIMM_C2
- -
-
-
-
DIMM_E1 DIMM_F2
- -
-
-
-
®
Intel Server System SR1670HV Service Guide
DIMM_C1
-
-
DIMM_F1
-
-
